Battery Heavy Object Impact Test Machine  I. Product Overview: In this test, the battery sample is placed on a flat surface, with a 15.8 mm diameter crossbar positioned at the center of the sample. A 9.1 kg weight is dropped from a specified height of 610 ± 25 mm onto the sample to simulate impact conditions II. Compliance Standards: IEC 62133 UN 38.3 UL 1642:1995 UL 2054:1997 GB/T 18287-2000 GB 8897.4-2002  III. Product Parameters Impact Weight 9.1 kg or 10 kg Drop Height 610 mm or 1000 mm Test Steel Rod φ15.8 mm Height Display Accuracy 1 mm Pressure Relief Device Located at the rear of the chamber, effective for pressure relief and explosion prevention Lighting Device LED high-brightness explosion-proof lamp Impact Method The impact weight is lifted to a set height and then released to fall freely in a vertical direction Internal Chamber Material SUS201 stainless steel plate External Chamber Material Cold-rolled steel plate with powder-coated finish Exhaust Fan Located at the back of the chamber, with a diameter of 120 mm and reserved exhaust duct Chamber Door Single-opening double-layer door with a tempered glass observation window and cold-drawn handle lock External Dimensions 680 x 830 x 1600 mm (L x W x H) Weight Approximately 130 kg Power Supply AC 220V, 50/60 Hz
