แบตเตอรี่กล่องทรงกระบอก 18650 26650 32650 21700 กล่องเซลล์ทรงกระบอกพร้อมฝาปิดป้องกันการระเบิดและโอริงฉนวน

Wechat:17720812054

Whatsapp:+86 13174506016

Email:David@batterymaking.com

  • รายการ NO.:

    TMAX-cylindrical-1
  • การชำระเงิน:

    L/C,T/T,Western Union, Paypal
  • เวลานำ:

    2 days
  • ใบรับรอง:

    CE ROHS Certificate
  • รายละเอียดผลิตภัณฑ์


แบตเตอรี่18650 26650 32650 21700เซลล์ทรงกระบอกกรณีที่มีการป้องกัน
ฝาครอบระเบิดและโอริงฉนวน


ข้อมูลจำเพาะ

แอปพลิเคชัน: ใช้สำหรับการวิจัยแบตเตอรี่ทรงกระบอก, การผลิต, โดยเฉพาะอย่างยิ่งสำหรับการผลิตแบตเตอรี่ทรงกระบอกที่ทรงพลัง

(100 ชุด / แพ็คเกจรวมเคสและฝาปิดเซลล์กระบอกสูบ)


กรณีเซลล์กระบอกสูบ 21700:

ข้อมูลจำเพาะ

ขนาด (เส้นผ่านศูนย์กลาง x สูง)

1.ขนาดเคส: 21.09mm(od) x 21.52mm(id) x 73.74mm(h);

2. ฝาบนมีโอริง : 20.95mm(d) x 4.2mm(h);

3. 18650 และ 38120 กระบอกเซลล์สามารถจัดหาได้

4 . สามารถจัดหาวัสดุ 304ss และ 316ss ได้.

วัสดุ

ตัวเรือนทำจากสแตนเลส 304

ตัวหมวกเป็นเหล็กชุบนิเกิล

ซีลโอริงทำจากไนลอน (อุปกรณ์เสริม)

ปะเก็นฉนวนทำจากpp

บันทึก

· สั่งขั้นต่ำ.: 100 ชิ้นต่อแพ็คเกจ

กรณีเซลล์กระบอกสูบ 26650:

ข้อมูลจำเพาะ

ขนาด (เส้นผ่านศูนย์กลาง x สูง)

· ตัวเรือน 26mm(od) x 25.5mm(id) x 68mm(h)

· ฝาครอบด้านบน: 25.5mm(d) x 5mm(h)

วัสดุ

· ตัวเรือนและฝาปิดทำจากเหล็ก A3 ชุบนิกเกิล และซีลโอริงทำจากไนลอน

น้ำหนัก

· 18.75 กรัม/ชิ้น

บันทึก

· แรงดันเปิดของวาล์วนิรภัย: 2 . 8mpa (วาล์วฝาจะเปิดเพื่อปล่อยแรงดันสูงภายในหากเกิน 2 . 8mpa เพื่อให้แน่ใจว่าไม่มีการระเบิดจากกระป๋อง)

กรณีเซลล์กระบอกสูบ 18650:

ข้อมูลจำเพาะ

หมวก

ฝาปิดที่มีเทอร์มิสเตอร์เทอร์มิสเตอร์ PTC ในตัว

ขนาด (เส้นผ่านศูนย์กลาง x สูง)

· ตัวเรือน: 18mm(od) x 17.5mm(id) x 67mm(h)

· ฝาครอบด้านบน: 17.5mm(d) x 4.05mm(h)

· ฉนวนด้านบน: 12.5mm(d) x 0.19mm(h)

· ฉนวนด้านล่าง: 12.5mm(d) x 0.19mm(h)

วัสดุ

· ตัวเรือนและฝาปิดทำจากเหล็ก A3 ชุบนิกเกิล และซีลโอริงทำจากไนลอน

น้ำหนัก

9.50 กรัม/ชิ้น

บันทึก

แรงดันเปิดของวาล์วนิรภัย: 2 . 5mpa (วาล์วฝาจะเปิดเพื่อปล่อยแรงดันสูงภายในหากเกิน 2 . 5mpa เพื่อให้แน่ใจว่าไม่มีการระเบิดจากกระป๋อง)

กล่องเซลล์กระบอกสูบ 32650:

ข้อมูลจำเพาะ

ขนาด (เส้นผ่านศูนย์กลาง x สูง)

· ตัวเรือน: 32mm(od) x 31.5mm(id) x 68mm(h)

· ฝาบน: 31.5mm(d) x 5.3mm(h)

วัสดุ

· ตัวเรือนและฝาปิดทำจากเหล็ก A3 ชุบนิกเกิล และซีลโอริงทำจากไนลอน

น้ำหนัก

· 28.85g/ชิ้น

บันทึก

· สั่งขั้นต่ำ.: 100 ชิ้นต่อแพ็คเกจ

(เราสามารถให้ราคาที่ประหยัดได้หากลูกค้าสั่งซื้อปริมาณมาก)
